产品说明
RG Series
The RG Series collaborative parallel electric gripper is an electric gripper mainly used with collaborative robots. It combines precise force control with industrial aesthetics, featuring high protection rating, plug-and-play usability and large load capacity.
Product Features
Full Series Specifications
|
Model
|
RG52-050
|
RG75-300
|
|
Adjustable Stroke
|
0-52mm
|
0-75mm
|
|
Single-Finger Gripping Force
|
2-50N
|
40-300N
|
|
Open/Close Time
|
0.65s
|
0.55s
|
|
Position Repeatability
|
±0.02mm
|
±0.02mm
|
|
*Max Recommended Load
|
1Kg
|
6kg
|
|
Drop Detection
|
Supported
|
Supported
|
|
Power-Off Holding
|
Supported
|
Supported
|
|
Operating Environment
|
5~40°C, below 85% RH
|
5~40°C, below 85% RH
|
|
Operating Noise
|
＜40dB
|
＜40dB
|
|
Body Weight
|
0.75Kg
|
1.5Kg
|
|
IP Rating
|
IP54
|
IP65
|
|
Rated Voltage
|
DC 24V±10%
|
DC 24V±10%
|
|
Max Current
|
0.8A
|
1.5A
|
|
Rated Current
|
0.5A
|
0.55A
|
|
Communication Protocol
|
Modbus RTU(RS 485) Digital I/O
|
Modbus RTU(RS 485)
|
|
International Standards Compliance
|
CE、RoHS
|
CE、RoHS
|
|
Permissible Static Load Fz (Vertical)
|
200N
|
400 N
|
|
Permissible Static Moment Mx
|
2.5N.m
|
8 N·m
|
|
Permissible Static Moment My
|
2N.m
|
8 N·m
|
|
Permissible Static Moment Mz
|
2.8N.m
|
8 N·m
|
