产品说明
EPG-HP Series
Based on the EPG Series electric gripper, Jodell has independently developed a series of high-precision products that meet the requirements of "high density, high rigidity, high precision".
Product Features
Full Series Specifications
|
Model
|
EPG-HP26-050
|
EPG-HP50-050
|
|
Adjustable Stroke
|
0-26mm
|
0-50mm
|
|
Single-Finger Gripping Force
|
5-50N
|
5-50N
|
|
Open/Close Time
|
0.35s
|
0.5s
|
|
Position Repeatability
|
±0.02mm
|
±0.02mm
|
|
*Max Recommended Load
|
1kg
|
1kg
|
|
Drop Detection
|
Supported
|
Supported
|
|
Operating Environment
|
5~40°C, below 85% RH
|
5~40°C, below 85% RH
|
|
Operating Noise
|
＜40dB
|
＜40dB
|
|
Body Weight
|
0.45kg
|
0.45kg
|
|
IP Rating
|
IP40
|
IP40
|
|
Rated Voltage
|
DC 24V±10%
|
DC 24V±10%
|
|
Max Current
|
0.6A
|
0.6A
|
|
Rated Current
|
0.25A
|
0.25A
|
|
Communication Protocol
|
Modbus RTU (RS 485), Digital I/O optional
|
Modbus RTU (RS 485), Digital I/O optional
|
|
International Standards Compliance
|
CE、RoHS
|
CE、RoHS
|
|
Permissible Static Load Fz (Vertical)
|
200N
|
200N
|
|
Permissible Static Moment Mx
|
3N·m
|
3N·m
|
|
Permissible Static Moment My
|
2.5N·m
|
2.5N·m
|
|
Permissible Static Moment Mz
|
3.5N·m
|
3.5N·m
|
Application Scenarios
