产品说明
ELS Series
The ELS Series is a micro electric table-type cylinder independently developed and manufactured by Jodell, featuring high energy density, large load capacity and compact design. It can be applied in various scenarios to accomplish complex tasks such as pick-and-place, arranging and processing.
Product Features
Full Series Specifications
|
Model
|
ELS-SW
|
ELS-SW
|
ELS-SW
|
ELS-30
|
ELS-30
|
ELS-30
|
ELS-50
|
ELS-50
|
ELS-50
|
|
Total Stroke
|
30，50mm
|
30，50mm
|
30，50mm
|
30mm
|
30mm
|
30mm
|
50mm
|
50mm
|
50mm
|
|
Lead Screw Pitch mm
|
2mm
|
4mm
|
6mm
|
2mm
|
4mm
|
6mm
|
2mm
|
4mm
|
6mm
|
|
Rated Thrust N
|
100N
|
50N
|
30N
|
100N
|
50N
|
30N
|
100N
|
50N
|
30N
|
|
Min Thrust N
|
30N
|
15N
|
9N
|
30N
|
15N
|
9N
|
30N
|
15N
|
9N
|
|
Max Speed mm/s
|
100mm/s
|
200mm/s
|
300mm/s
|
100mm/s
|
200mm/s
|
300mm/s
|
100mm/s
|
200mm/s
|
300mm/s
|
|
Max Acceleration G
|
0.3
|
0.3
|
0.3
|
0.3
|
0.3
|
0.3
|
0.3
|
0.3
|
0.3
|
|
Max Payload - Horizontal kg
|
6kg
|
3kg
|
2kg
|
6kg
|
3kg
|
2kg
|
6kg
|
3kg
|
2kg
|
|
Max Payload - Vertical kg
|
1.5kg
|
0.75kg
|
0.5kg
|
1.5kg
|
0.75kg
|
0.5kg
|
1.5kg
|
0.75kg
|
0.5kg
|
|
Position Repeatability mm
|
±0.02mm
|
±0.02mm
|
±0.02mm
|
±0.02mm
|
±0.02mm
|
±0.02mm
|
±0.02mm
|
±0.02mm
|
±0.02mm
|
|
Body Width mm
|
36mm
|
36mm
|
36mm
|
45mm
|
45mm
|
45mm
|
45mm
|
45mm
|
45mm
|
|
Feature Description
|
Position Mode / Push Mode
|
Position Mode / Push Mode
|
Position Mode / Push Mode
|
Position Mode / Push Mode
|
Position Mode / Push Mode
|
Position Mode / Push Mode
|
Position Mode / Push Mode
|
Position Mode / Push Mode
|
Position Mode / Push Mode
|
|
Communication Protocol
|
Built-in: Modbus RTU (RS485)
Digital I/O, IO-Link optional |
Built-in: Modbus RTU (RS485)
Digital I/O, IO-Link optional |
Built-in: Modbus RTU (RS485)
Digital I/O, IO-Link optional |
Built-in: Modbus RTU (RS485)
Digital I/O, IO-Link optional |
Built-in: Modbus RTU (RS485)
Digital I/O, IO-Link optional |
Built-in: Modbus RTU (RS485)
Digital I/O, IO-Link optional |
Built-in: Modbus RTU (RS485)
Digital I/O, IO-Link optional |
Built-in: Modbus RTU (RS485)
Digital I/O, IO-Link optional |
Built-in: Modbus RTU (RS485)
Digital I/O, IO-Link optional |
|
Recommended Operating Environment
|
0~40°C，＜85% RH
|
0~40°C，＜85% RH
|
0~40°C，＜85% RH
|
0~40°C，＜85% RH
|
0~40°C，＜85% RH
|
0~40°C，＜85% RH
|
0~40°C，＜85% RH
|
0~40°C，＜85% RH
|
0~40°C，＜85% RH
|
|
Cable Exit Method
|
Rear cable exit / Side cable exit
|
Rear cable exit / Side cable exit
|
Rear cable exit / Side cable exit
|
Rear cable exit / Side cable exit
|
Rear cable exit / Side cable exit
|
Rear cable exit / Side cable exit
|
Rear cable exit / Side cable exit
|
Rear cable exit / Side cable exit
|
Rear cable exit / Side cable exit
|
|
Travel Life
|
50 million cycles / 5000 km
|
50 million cycles / 5000 km
|
50 million cycles / 5000 km
|
50 million cycles / 5000 km
|
50 million cycles / 5000 km
|
50 million cycles / 5000 km
|
50 million cycles / 5000 km
|
50 million cycles / 5000 km
|
50 million cycles / 5000 km
|
|
Rated Voltage V
|
DC 24V ±10%
|
DC 24V ±10%
|
DC 24V ±10%
|
DC 24V ±10%
|
DC 24V ±10%
|
DC 24V ±10%
|
DC 24V ±10%
|
DC 24V ±10%
|
DC 24V ±10%
|
|
Rated Current A
|
1.5A
|
1.5A
|
1.5A
|
1.5A
|
1.5A
|
1.5A
|
1.5A
|
1.5A
|
1.5A
|
|
Peak Current A
|
3A
|
3A
|
3A
|
3A
|
3A
|
3A
|
3A
|
3A
|
3A
|
|
Rated Power W
|
20W
|
20W
|
20W
|
20W
|
20W
|
20W
|
20W
|
20W
|
20W
|
|
Motor Type
|
DC Servo Motor
|
DC Servo Motor
|
DC Servo Motor
|
DC Servo Motor
|
DC Servo Motor
|
DC Servo Motor
|
DC Servo Motor
|
DC Servo Motor
|
DC Servo Motor
|
|
Permissible Static Load Moment Mx
|
32N·m
|
32N·m
|
32N·m
|
32N·m
|
32N·m
|
32N·m
|
32N·m
|
32N·m
|
32N·m
|
|
Permissible Static Load Moment My
|
20N·m
|
20N·m
|
20N·m
|
20N·m
|
20N·m
|
20N·m
|
20N·m
|
20N·m
|
20N·m
|
|
Permissible Static Load Moment Mz
|
23N·m
|
23N·m
|
23N·m
|
23N·m
|
23N·m
|
23N·m
|
23N·m
|
23N·m
|
23N·m
|
|
Permissible Dynamic Load Moment Mx
|
12.5N·m
|
12.5N·m
|
12.5N·m
|
12.5N·m
|
12.5N·m
|
12.5N·m
|
12.5N·m
|
12.5N·m
|
12.5N·m
|
|
Permissible Dynamic Load Moment My
|
10N·m
|
10N·m
|
10N·m
|
10N·m
|
10N·m
|
10N·m
|
10N·m
|
10N·m
|
10N·m
|
|
Permissible Dynamic Load Moment Mz
|
10N·m
|
10N·m
|
10N·m
|
10N·m
|
10N·m
|
10N·m
|
10N·m
|
10N·m
|
10N·m
|
|
Protection Rating
|
IP40
|
IP40
|
IP40
|
IP40
|
IP40
|
IP40
|
IP40
|
IP40
|
IP40
|
|
International Standards Compliance
|
CE，FCC，RoHS
|
CE，FCC，RoHS
|
CE，FCC，RoHS
|
CE，FCC，RoHS
|
CE，FCC，RoHS
|
CE，FCC，RoHS
|
CE，FCC，RoHS
|
CE，FCC，RoHS
|
CE，FCC，RoHS
|
|
Mounting Method
|
Horizontal, vertical,
side or ceiling mounting |
Horizontal, vertical,
side or ceiling mounting |
Horizontal, vertical,
side or ceiling mounting |
Horizontal, vertical,
side or ceiling mounting |
Horizontal, vertical,
side or ceiling mounting |
Horizontal, vertical,
side or ceiling mounting |
Horizontal, vertical,
side or ceiling mounting |
Horizontal, vertical,
side or ceiling mounting |
Horizontal, vertical,
side or ceiling mounting |
Application Scenarios
